Infrared thermal imager is a device that captures infrared radiation (thermal radiation) from the surface of objects and converts it into a visible thermal image, which non-contact temperature measurement: surface temperature distribution can be obtained without contacting the target, avoiding interference or damage to the measured object;

1. Display: ≥3.5 inches, supports screen brightness adjustment, sampling frame rate is not lower than 60 frames/second.★

2. Detector pixels: ≥384×288.

3. Temperature range: -40℃ to 1200℃.

4. Noise Equivalent Temperature (NETD): ≤50mK.

5. Working wavelength: 8-14 μm.

6. Image modes: ≥8 modes, support white hot, black hot, fire, flame, search and rescue, picture-in-picture, visible light and fusion, etc., with temperature measurement value, battery consumption, temperature scale, photo or video state display function.★

7. Zoom function: supports 2x, 4x digital zoom.

8. With infrared mode and visible light mode, 2 modes can be quickly switched, and the visible light resolution ≥ 5 million pixels. ★

9. Support for real-time viewing of captured and saved images and videos on the device, and support for deleting videos and images on the device.★

10. With laser indication function, electronic compass orientation function, cold and hot spot tracking function, full screen automatic tracking of the highest and lowest temperatures, it can display the highest, lowest temperature and center point temperature at the same time.★

11. With laser ranging function, it can measure and display the straight-line distance between the tested object and the host;★

12. Laser rangefinder range: ≥600m;

13. Duration of work in specific environmental high-temperature environment: 80℃, ≥30min; 120℃, ≥10min; 260℃, ≥5min;

14. Protection level: IP67. ★

15. The top of the main machine is equipped with a metal hook, equipped with a telescopic buckle, which can hang the thermal imager on the chest, the telescopic buckle vertical load capacity ≥ 20Kg, the retraction force ≥ 1.5Kg, the extendable length ≥ 50cm.★

16. Host (with battery) mass: ≤800g, host dimensions: ≤205mm*110mm*80mm. ★

17. Power supply mode: using detachable lithium battery power supply, battery life ≥ 4h/piece, the main unit and battery are equipped with Type-C interface, supporting local charging and direct battery charging.★

18. Working temperature: excellent in the range of -20℃~+60℃.

19. Meets the requirements of XF/T 635-2023 "Infrared Thermal Imager for Firefighting". ★

20. It is necessary to have a shock-absorbing buffer protection device that meets the 2-meter drop test;
